Proflow Warlord Extreme LS3 Aluminium Engine Block

When serious horsepower demands more than a factory LS block can deliver, Proflow’s Extreme Warlord LS3 Aluminium Engine Block provides the strength, rigidity and oiling performance required for high-output engine combinations.

Designed around the proven LS3 architecture, this aftermarket block is manufactured from A356-T6 aluminium to provide an excellent combination of strength and reduced weight. With a 4.125" bore, 9.240" deck height, heavy-duty cylinder sleeves and billet steel splayed main caps, it provides a strong foundation for large-capacity naturally aspirated engines, supercharged combinations and high-boost turbocharged builds. It also has provision for 6-bolt cylinder heads (top additional bolt holes need to be tapped/finished).

The block incorporates extra-thick ductile iron cylinder sleeves to handle increased cylinder pressures and provide additional material for performance engine machining. The bottom end is reinforced with billet steel main caps and 7/16" main studs, helping maintain crankshaft stability under high cylinder loads and elevated engine speeds.

A priority main oiling system directs oil to the main bearings before supplying other areas of the engine, helping maintain consistent lubrication where it matters most during demanding performance use.

Key Features:

• LS3-style aftermarket aluminium engine block
• High-strength A356-T6 aluminium construction
• 4.125" finished bore
• 9.240" deck height
• 1/2" head studs / 7/16" mains
• Extra-thick ductile iron cylinder sleeves
• Heavy-duty billet steel main caps
• Priority main oiling system
• Designed for high-horsepower naturally aspirated and forced-induction applications
• Suitable for large-displacement LS engine combinations
• No AFM provisions
• Engineered for applications approaching 1,800–2,000 HP, depending on engine specification, machining, tune and overall combination

Specifications:

Note: Head stud kit to suit is ARP-234-4350

*Maximum power capability is dependent on engine configuration, machining, rotating assembly, fasteners, cylinder pressures, tuning and intended use.
